Machine:
| Emissions Tier (EPA) | Tier 4 | Tier 4 |
| Engine Fuel | Diesel | Diesel |
| Maximum Governed RPM | 2,500 rpm | 2,500 rpm |
| Horsepower | 33.5 hp | 33.5 hp |
Performance:
| Operating Weight | 7,183 lb | 7,858 lb |
| Weight Class | 3.3 t | 3.6 t |
| Travel Speed - High/Low | 2.9mph/1.6mph | 2.9mph/1.6mph |
| Arm Digging Force | 4,589 lbf | 3,986 lbf |
| Bucket Digging Force | 6,968 lbf | 6,968 lbf |
| Rated Lift Capacity | 2537 lb | 2481 lb |
| Lift Radius | 118 in | 118 in |
| Boom Swing - Left/Right | 75° | 55° |
| Maximum Dig Depth | 10.2 ft | 11.2 ft |
| Max Dump Height | 11 ft | 11.5 ft |
Capacities:
| Fuel Tank | 14 gal |
Hydraulic System:
| Auxiliary Std Flow | 16.9 gal/min | 16.9 gal/min |
| Auxiliary Pressure | 2,987 psi | 2,987 psi |
Dimension:
| Length | 183.5 in | 187.5 in |
| Overall Length in Travel Position | 183.5 in | 187.5 in |
| Width | 59.8 in | 60 in |
| Height with Operator Cab | 95.6 in | 95.6 in |
